Manual stacker HX21031
Quick Details
Feature: Manual stacter Condition: New Application: Warehouse/Logistic Certification: ISO, CE Model Number:HX21031 Rated load capacity: 1000-3000kg Lifting height: 1600-2000 mm Min. turning radius: 1250 mm Dimension: 1380*850*2100 mm Place of origin: shandong china Warranty: 1 year After-sale Service : Any time available
Packaging&Delivery
Packaging Details: Nude package shipped by Ro-Ro or Bulk shipment
Delivery Detail: 10-35 days
Main Features
1.More excellent performance
2.More reliable quality
3.Easier to operate
4.Easier to maintain
5.More energy-efficient and environmental friendly
Technical Parameters
| Dimension | Unit | HX21031 | HX21032 | HX21033 | HX21034 | HX21035 |
| Overall length | mm | 1380 | 1380 | 1380 | 1380 | 1400 |
| Overall width | mm | 850 | 850 | 850 | 850 | 850 |
| Overall heigh | mm | 2100 | 2100 | 2100 | 2400 | 2100 |
| Fork length | mm | 1000 | 1000 | 1000 | 1000 | 1000 |
| Fork width | mm | 300-850 | 320-850 | 320-850 | 680 | 680 |
| Weight | ||||||
| Overall weight | kg | 255 | 265 | 290 | 330 | 365 |
| Rated load capacity | kg | 1000 | 1500 | 2000 | 2000 | 3000 |
| Main performance | ||||||
| Max. Lifting height | mm | 1600 | 1600 | 1600 | 2000 | 1600 |
| Max. lowered height | mm | 90 | 90 | 90 | 90 | 90 |
| Load centre | mm | 400 | 400 | 400 | 400 | 400 |
| Front/rear wheel tread | mm | 1000 | 1000 | 1000 | 1000 | 1000 |
| Min. Turning radius | mm | 1250 | 1250 | 1250 | 1250 | 1250 |
