Trailer hand-lifting mobile lighting tower 4TN4000
Quick Details
Feature: Mobile lighting vehicle Condition: New Application: Construction Certification: ISO, CE Model Number:4TN4000 Lamp source type:LED Operating Weight: 960 kg Power lamp quantity: 4*1000 w Luminous flux: 440000 lm Continous working time:65 h Dimension:4360*1430*1450 mm Place of Origin : Shandong china Warranty: 1 year After-sale Service : Any time availbal
Packaging&Delivery
Packaging Details: Nude package shipped by Ro-Ro or Bulk shipment
Delivery Detail: 10-35 days
Main Features
1.More excellent performance
2.More reliable quality
3.Easier to operate
4.Easier to maintain
5.More energy-efficient and environmental friendly
Technical Parameters
| Dimention | Unit | 4TN4000 |
| Length | mm | 4360 |
| Width | mm | 1430 |
| Height | mm | 1450 |
| Weight | ||
| Operating weight | kg | 960 |
| Power | ||
| Generator brand | KUBOTA | |
| Generator model | D1105 | |
| Generator type | Three cylinder，Water-cooled four-stroke | |
| Generator rated power | Kw/ram | 12.6/1500 |
| Burning method | E-TVS | |
| Intake method | Naturally aspirated | |
| Emission class | conventional | |
| Generator standard configuration | Sparks | |
| Rated voltage(50/60hz) | V | 230/240-120 |
| Continuous working time | H | 65 |
| Motor insulation class | H | |
| Motor protection class | IP23 | |
| Main performance | ||
| Lamp | Metal halide lamp | |
| Power lamp quantity | Pcs | 1000W*4 |
| Luminous flux | Lm | 440000 |
| Num. Of pole sectons | 3 | |
| Unit start method | Key start method | |
| Max. Wind speed | m/s | 20 |
| Noise level | Db | 72 at 7 meters |
| Suspension &Brakes | Leaf spring suspension&Single axle without brake | |
| Drawbar | Adjustable lever with retractable adjustable guide wheel | |
| Max. Lift height | m | 9 |
| Tire size | ‘’ | 14 |
| Max. Traction speed | Km/h | 80 |
| Fuel tank capacity | L | 110 |
