Wheel Loader SHM-956
Quick Details
Feature: Wheel Loader Condition: New Application: Construction Model Number: SHM-956 Certification: ISO, CE Rated loading capacity: 5.0T Bucket Capacity : 3.0m³ Dimension:8250*2880*3570mm Place of Origin : Shandong china Max. Lifting Load: 5.0T Engine:WD615G220 Warranty: 1 year Color: Yellow After-sale Service : Any time availbal
Packaging&Delivery
Packaging Details: Nude package shipped by Ro-Ro or Bulk shipment
Delivery Detail: 10-35 days
Main Features
1.More excellent performance
2.More reliable quality
3.Easier to operate
4.Easier to maintain
5.More energy-efficient and environmental friendly
Technical Parameters
| Dimention | Unit | SHM-956 |
| Overall length | mm | 8250 |
| Overall width | mm | 2880 |
| Overall height | mm | 3570 |
| Bucket width | mm | 2950 |
| Weight | ||
| Operating weight | kg | 16950 |
| Rated load | kg | 5000 |
| Power | ||
| Engine manufacturer | WEICHAI | |
| Engine model | WD615G | |
| Type | in-line, water cooled ,dry liner direct injection | |
| No. Of cylinder-diameter*stroke | 6-126*130 | |
| Engine rated power/speed | Kw/rps | 162/2200 |
| Max torque | N.m | 980 |
| Min fuel consumer ratio | kw/h | ≤213 |
| Travel | ||
| Travel max speed | km/h | 38 |
| Transmission system | ||
| Transmission model | YJ320B-I | |
| Gearbox model | Power shaft normallly engaged straight gear | |
| Torque converter type | Variable-speed transmission | |
| Gears | 4F/4R | |
| Drive axles | ||
| Main reducing spiral | Bevel gear grade reduction | |
| Decelerating mode | Planetary reduction grade I | |
| Main performance | ||
| Rated load | t | 5000 |
| Operation weight | t | 16950 |
| Bucket capacity | m³ | 3.0 |
| Max tractiong force | kn | 145 |
| Max breakout force | kn | 175 |
| Max grade ability | ° | 28 |
| Max dumping height | mm | 3150 |
| Max dumping reach | mm | 1250 |
| Min turning radius | mm | 5950 |
| Wheel base | mm | 3250 |
| Ground clearance | mm | 450 |
| Tread | mm | 2250 |
| Service brake | Air over-oil caliper disc brake for four wheels | |
| Parking brake | Manual caliper disc brake | |
| Automatic bucker leveling function | Yes | |
| Diseal capacity | L | 230 |
| Tyre specification | 23.5–25 | |
| Front Tyre pressure | Mpa | 0.4 |
| Rear tyre pressure | Mpa | 0.35 |
